Paver Block Making Machine，UNT1200B

Classification:

High Quality Block Making Machine

Related products
Get Quote
  • Product Description
  • Project
    • Commodity name: Paver Block Making Machine，UNT1200B
    • Commodity ID: UNT1200B

    UNT1200B block making machine has been manufactured a high-efficiency model to meet the various customer requirements with easy operation, lower failure ratio and high reliability automatic control, With a simple mold change , concrete block making machines can manufacture customized concrete product like special-shape blocks, paving stone and building blocks ect.


    Main features:

    1.The proportion description formality of the storing material can be changed different materials forming parameter in real time.
    2. The four-axis synchronous vibration system integrates a number of technologies such as computer control, Schneider frequency conversion system, and motor drive control.charging and pressing time can be adjusted according to different materials and different products.
    3.Three operation modes “fully automatic”,Semi automatic” and “manual” can ensure the continuous manufacturing process
    4.The faults can be diagnosed automatically and the machine will send warn signals to ensure safety in production
    5.Double high-dynamic proportional valves can adjust the oil flow and pressure in automatic


    Technical specifications:

    Overall dimension 3725×2100×3285mm Vibration method Synchronous mode of table & mould
    Pallet size 1100×950×30-40mm Vibration frequency 50-70Hz
    Working area 1070×910mm Machine power 63.45kW
    Machine weight 13800kg Cycle time 15s-20s depending on the product size



    Production Capacity

    Specification of products (mm) Number of blocks per pallet Pieces/ hour Pieces/8 hours
    Block UNIK 400×200×200 10 2,400 19,200
    Hollow Block UNIK 400×100×200 18 3,240 25,920
    Interlock Paver UNIK 225×112.5×60 24 5,760 46,080
    Rectangular Paver UNIK 200×100×60/80 36 8,640 69,120

    Paver Block Making Machine is a mechanical device used for the production of paver blocks. These blocks are commonly used for the construction of roads, pavements, walkways, and driveways. The machine comes in different models and sizes, depending on the production capacity and the type of paver block being produced.

    The Paver Block Making Machine uses hydraulic pressure to compress and mold the cement, sand, and other materials used in the paver block production. It comes with various molds that allow for the production of different sizes and shapes of paver blocks. The machine is easy to operate and requires minimal maintenance, making it a cost-effective solution for the production of paver blocks.

    The Paver Block Making Machine has a significant impact on the construction industry, mainly due to its efficiency and effectiveness. It enables faster production of paver blocks, significantly reducing the time and labor required for manual production. Moreover, the machine ensures uniformity in the size and shape of the paver blocks, ensuring a high level of quality in construction projects.

    In conclusion, the Paver Block Making Machine is a vital machine in the construction industry. It offers a cost-effective solution for the production of high-quality paver blocks, making it a must-have for any construction project.

  •
